Major Tech

Major Tech 1000V Voltage Tester

SKU: MT478

A professional two-pole voltage, continuity and phase tester with LED, LCD, audible and vibration indication.

Available to SourceIEC 61010-1CAT III 1000VCAT IV 600VIP64

Price on Request

Qty:

Optional note (application / requirements)

Request Technical Advice

Download Technical Datasheet

Key Benefits

Voltage Indication to 1000V AC/DC

LED indication from 12V to 1000V AC/DC; LCD voltage measurement from 6V to 1000V AC/DC.

LED and Backlit LCD Indication

2000-count backlit LCD combined with multi-level LED voltage indication for clear readings in any light.

Audible and Vibration Feedback

Continuity buzzer and vibration during load operation, similar to traditional solenoid testers.

Rotary-Field and Phase Testing

Rotary-field direction indication for three-phase systems plus single-pole phase testing.

IP64 Rugged Housing with Flashlight

Heavy-duty moulded IP64 case with integrated flashlight, cord wear indicator and probe protector.

Technical Specifications

DC Voltage	12V to 1000V
AC Voltage	12V to 1000V
Voltage Accuracy	±(3.0% +5)
Rotary Field	100V to 400V
RCD Test	30mA at 230V
Resistance	0 to 1999Ω
AC Bandwidth	50/60Hz
Digital Display	2000-count LCD
Low Input Impedance	< 6kΩ
Protection Rating	IP64
Size	240 × 78 × 30mm
Weight	237g

IEC 61010-1CAT III 1000VCAT IV 600V

Features

2000-count backlit LCD
LED indication from 12V to 1000V AC/DC
LCD voltage measurement from 6V to 1000V AC/DC
Fixed impedance approximately 200kΩ
Switchable load using two push buttons
Vibration during load
Rotary-field direction indication
Continuity buzzer
Diode test
Integrated flashlight
4mm probe-tip thickness
Screw-on probe-tip extensions
Heavy-duty moulded IP64 case
Cord wear indicator
Probe protector

Applications

EV service workshopsAutomotive electrical servicingIndustrial electrical maintenanceElectrical training facilitiesFleet-maintenance workshopsHigh-voltage workshop supportControlled testing and fault-finding procedures

Safety Notice

Electrical testing must only be performed by appropriately trained and authorised personnel. Confirm that the instrument, test leads, accessories, measurement category and voltage rating are suitable for the specific task. Follow approved isolation, lockout, voltage-verification and PPE procedures. Instrument ratings do not remove the need for risk assessment, correct PPE or safe working procedures.
